The OREI HDS-104 is designed to duplicate one HDMI input signal to four identical HDMI outputs, ideal for displaying the same content on multiple screens. This splitter does not extend monitors; it only mirrors the input signal. It supports HDMI cables up to 30 feet for optimal performance. This 4K 18 Gbps powered HDMI splitter is compatible with HDMI 2.0 and HDCP 2.2. It delivers resolutions up to 4K@60Hz, as well as 1080p, 720p, VGA, and WUXGA. It also supports advanced audio formats, including LPCM, Dolby-AC3, DTS7.1, DSD, Dolby TrueHD, and DTS-HD Master Audio, ensuring excellent sound quality.
Its compact size and plug-and-play installation make it easy to set up, while its EDID management ensures compatibility with various displays. Perfect for commercial or home use requiring multiple displays.
[tab]
| Input: | 1 × HDMI Type A (19-pin female) |
| Output: | 4 × HDMI Type A (19-pin female) |
| Video Bandwidth: | 18 Gbps |
| Video Resolution: | Up to 4K@60Hz and 2k@60Hz |
| Color Space: | YUV 4:2:2, YUV 4:4:4, YUV 4:2:0, RGB |
| HDMI Audio Formats: | LPCM 7.1, Dolby TrueHD, and DTS-HD Master Audio |
| HDMI Compliance | HDMI 2.0b |
| HDCP Compliance | HDCP 2.2 |
| Power Supply: | Input: AC 100-240V 50/60Hz Output: DC 5V/1A |
| Power Consumption: | 2W (Max) |
| Operating Temperature: | 0°C ~ 40°C / 32°F ~ 104°F |
| Storage Temperature: | -20°C ~ 60°C / -4°F ~ 140°F |
| Relative Humidity: | 20 ~ 90% RH (Non-condensing) |
| Height: | 25 mm / 0.98in |
| Width: | 70 mm / 2.75in |
| Depth: | 145 mm / 5.70in |
| Weight: | 300 g / 10.58oz |
| REGULATORY: | CE | FCC | RoHS |
| 1 × HDS-104 1×4 HDMI Splitter |
| 1 × Power Adapter |
| 1 × User Manual |
| 1 - Year Manufacturer's Warranty |
[/tab]
[tab1]
Our splitters will not work with capture cards due to the HDCP encryption on the output
Our HDMI splitter will duplicate or "mirror" a single HDMI source on two HDMI displays. Both displays will show the same video and audio simultaneously
Our splitter does not support extend mode. It only supports mirror/duplicate screen function, each screen will show the same picture
Yes, the power adapter does support 220V
You can use standard HDMI cables up to 15 feet and high quality cables up to 30 feet.
However, you can use fiber optic active HDMI cables up to 200 feet. If its not a high quality cable then you may lose the signal in some instances.
No, the HDMI splitters do not support CEC because most customers do not want all the TV's to turn ON as soon as the source is turned ON.
The output resolution support up to 4K x 2K@30Hz,1080P@120Hz,and 1080P 3D@60Hz.
DTS-HD/Dolby-true-HD/LPCM 7.1/DTS/Dolby-AC3/DSD
It supports HDMI 1.4A
[/tab1]
